Chapter 4 Digital Output Settings (DIGITAL OUTPUT)
45
Level 1
Level 2
Level 3
Setting item
Setting value
HDMI
InfoFrame/
Packet
Vendor
Specific
InfoFrame
3D F Ext Data
7: Quincunx E/L, E/R
Quincunx matrix
Even/Left picture, Even/Right picture
Additional Pre
* Only displayed when 3D Valid
= 1 is selected.
0 (Not Present) / 1
Dual View
* Only displayed when 3D Valid
= 1 is selected.
0: Normal 3D/ 1: Dual View
View Dependency
* Only displayed when 3D Valid
= 1 is selected.
0: No Indication
1: Right Originate
2: Left Originate
3: Both
Preferred 2D
* Only displayed when 3D Valid
= 1 is selected.
0: No Indication
1: Right View
2: Left View
Disparity Pre
* Only displayed when 3D Valid
= 1 is selected.
0 (Not Present) / 1
Disparity Ver
* Only displayed when 3D Valid
= 1 is selected.
0 to 3
Disparity Length
* Only displayed when 3D Valid
= 1 is selected.
Disparity Ver = when at 0
Length = 0
Disparity Ver = when at 1
Length = 3
Disparity Ver = when at 2
Disparity Data1 = 2h : Length = 3
Disparity Data1 = 3h : Length = 4
Disparity Data1 = 4h : Length = 5
Disparity Data1 = 5h : Length = 6
Disparity Data1 = ah : Length = 11
Disparity Data1 = 11h : Length = 18
Disparity Data1 = else : Length = 1
Disparity Ver = when at 3
Disparity Data4 = 0h : Length = 4
Disparity Data4 = 2h : Length = 6
Disparity Data4 = 3h : Length = 7
Disparity Data4 = 4h : Length = 8
Disparity Data4 = 5h : Length = 9
Disparity Data4 = ah: Length = 14
Disparity Data4 = else : Length = 4
Disparity Data 1 to 20
* Only displayed when 3D Valid
= 1 is selected.
00h to FFh
Meta Present
* Only displayed when 3D Valid
= 1 is selected.
0 (Not Present) / 1
Metadata Type
* Only displayed when 3D Valid
= 1 is selected.
0 (fixed)
Metadata Length
* Only displayed when 3D Valid
= 1 is selected.
Because VSI InfoFrame is a
maximum of 27 bytes, the
maximum Length relies on
other Data length.
0 to 20
