Chapter 4 Digital Output Settings (DIGITAL OUTPUT)
46
Level 1
Level 2
Level 3
Setting item
Setting value
HDMI
InfoFrame/
Packet
Vendor
Specific
InfoFrame
Metadata Data 1 to 20,
* Only displayed when 3D Valid
= 1 is selected.
Because VSI InfoFrame is a
maximum of 27 bytes, the
maximum Length relies on
other Data length.
00h to FFh
AVI InfoFrame
OFF/ON
0: OFF / 1: ON
Type :
2 (fixed)
Version :
1 to 3
Scan Info
0: No Data
1: Overscanned
2: Underscanned
Bar Info
0: Data Not Valid
1: Vertical Valid
2: Horizontal Valid
3: Vert.&Horiz. Valid
ActiveF Info
0: No Data / 1: Valid
RGB or YCbCr
0: RGB
1: YCbCr 4:2:2
2: YCbCr 4:4:4
3: YCbCr 4:2:0
4: (reserved1)
5: (reserved2)
6: (reserved3)
7: IDO-Defined
ActiveF Aspect
0: Same Picture
1: 4:3(center)
2: 16:9(center)
3: 14:9(center)
4: box 16:9(top)
5: box 14:9(top)
6: box>16:9(center)
7: 4:3(14:9 center)
8: 16:9(14:9 center)
9: 16:9(4:3 center)
Picture Aspect
0: No Data / 1:4:3 / 2:16:9
Scaling
0: Unknown
1: Horizontal
2: Vertical
3: Horiz. & Vert.
Colorimetry
0: No Data
1: SMPTE170M/ITU601
2: ITU709
3: Extended Valid
Video Code :
0 to 107
Repetition :
1 to 10
Top Bar :
0 to 65535
Sets Line Number of End of Top Bar.
(Sets letter BOX upper Bar size.)
Bottom Bar :
0 to 65535
Sets Line Number of Start of Bottom Bar.
(Sets letter BOX lower Bar size.)
Left Bar :
0 to 65535
Sets Pixel Number of End of Left Bar.
(Sets pillar BOX left side Bar size.)
