Chapter 4 Digital Output Settings (DIGITAL OUTPUT)
47
Level 1
Level 2
Level 3
Setting item
Setting value
HDMI
InfoFrame/
Packet
AVI InfoFrame
Right Bar :
0 to 65535
Sets Pixel Number of Start of Right Bar.
(Sets pillar BOX right side Bar size.)
RGB Quan.Range
0:Default
1: Limited Range
2: Full Range
YCC Quan.Range
0: Limited Range / 1: Full Range
Extended Colo
Referenced when Extended
Valid is set in Colorimetry.
0: xvYCC601
1: xvYCC709
2: sYCC601
3: AdobeYCC601
4: AdobeRGB
5: BT2020 YcCbcCrc
6: BT2020 RGBorYCbCr
IT content
0: No Data / 1: IT content
IT contentType
0: Graphics
1: Photo
2: Cinema
3: Game
SPD InfoFrame
OFF/ON
0: OFF / 1: ON
Type :
3 (fixed)
Version :
1 (fixed)
Vendor Name :
Maximum of 8 characters
(0x20 to 0x7E ASCII 7 bit)
Product Description:
Maximum of 16 characters
(0x20 to 0x7E ASCII 7 bit)
Source Device
0: Unknown
1: Digital STB
2: DVD player
3: D-VHS
4: HDD Video recorder
5: DVC
6: DSC
7: Video CD
8: Game
9: PC general
A: Blu-Ray Disc
B: Super Audio CD
C: HD DVD
D: PMP
Audio
InfoFrame
OFF/ON
0: OFF / 1: ON
Type :
4 (fixed)
Version :
1 (fixed)
Coding Type
0: Refer StreamHeader
1: IEC60958 PCM
2: AC-3
3: MPEG1 (Layers 1&2)
4: MP3 (MPEG1 Layer 3)
5: MPEG2 (multi ch.)
6: AAC
7: DTS
8: ATRAC
9: One Bit Audio
A: Dolby Digital+
B: DTS-HD
C: MLP
D: DST
E: WMA Pro
F: Refer Extension
