Chapter 4 Digital Output Settings (DIGITAL OUTPUT)
49
Level 1
Level 2
Level 3
Setting item
Setting value
HDMI
InfoFrame/
Packet
Audio
InfoFrame
26
FRC
FLC
-
RC
FC
-
FR
FL
27
FRC
FLC
-
RC
FC
LFE
FR
FL
28
FRC
FLC
RR
RL
-
-
FR
FL
29
FRC
FLC
RR
RL
-
LFE
FR
FL
30
FRC
FLC
RR
RL
FC
-
FR
FL
31
FRC
FLC
RR
RL
FC
LFE
FR
FL
32
-
FCH
RR
RL
FC
-
FR
FL
33
-
FCH
RR
RL
FC
LFE
FR
FL
34
TC
-
RR
RL
FC
-
FR
FL
35
TC
-
RR
RL
FC
LFE
FR
FL
36
FRH
FLH
RR
RL
-
-
FR
FL
37
FRH
FLH
RR
RL
-
LFE
FR
FL
38
FRW
FLW
RR
RL
-
-
FR
FL
39
FRW
FLW
RR
RL
-
LFE
FR
FL
40
TC
RC
RR
RL
FC
-
FR
FL
41
TC
RC
RR
RL
FC
LFE
FR
FL
42
FCH
RC
RR
RL
FC
-
FR
FL
43
FCH
RC
RR
RL
FC
LFE
FR
FL
44
TC
FCH
RR
RL
FC
-
FR
FL
45
TC
FCH
RR
RL
FC
LFE
FR
FL
46
FRH
FLH
RR
RL
FC
-
FR
FL
47
FRH
FLH
RR
RL
FC
LFE
FR
FL
48
FRW
FLW
RR
RL
FC
-
FR
FL
49
FRW
FLW
RR
RL
FC
LFE
FR
FL
50
Reserved
Level Shift Value :
0 to 15 [dB]
Down-mix
0: Permitted/No Info
1: Prohibited
LFE PB Level
0: Unknown
1: 0dB Playback
2: +10dB Playback
MPEG
InfoFrame
OFF/ON
0: OFF / 1: ON
Type :
5 (fixed)
Version :
1 (fixed)
Bit Rate :
0 to 4294M967k295 [Hz]
Field Repeat
0: New Field(picture)
1: Repeated Field
Frame
0: Unknown(No Data)
1: I Picture
2: B Picture
3: P Picture
NTSC VBI
InfoFrame
OFF/ON
0: OFF / 1: ON
Type :
6 (fixed)
Version :
1 (fixed)
PES Length :
0 to 27
PES 1-27 :
0x0 to 0xFF
Dynamic
Range and
Mastering
InfoFrame
OFF/ON
0: OFF / 1: ON
Type :
7 (fixed)
Version :
1 (fixed)
EOTF
0: SDR Range
1: HDR Range
2: SMPTE ST2084[2]
3: Future EOTF
Metadata ID
Metadata Type1 (fixed)
Disp Primaries x0
0.00000 to 1.00000 (0.00002Step)
Disp Primaries y0
0.00000 to 1.00000 (0.00002Step)
