Chapter 4 Digital Output Settings (DIGITAL OUTPUT)
50
Level 1
Level 2
Level 3
Setting item
Setting value
HDMI
InfoFrame/
Packet
Dynamic
Range and
Mastering
InfoFrame
Disp Primaries x1
0.00000 to 1.00000 (0.00002Step)
Disp Primaries y1
0.00000 to 1.00000 (0.00002Step)
Disp Primaries x2
0.00000 to 1.00000 (0.00002Step)
Disp Primaries y2
0.00000 to 1.00000 (0.00002Step)
White Point x
0.00000 to 1.00000 (0.00002Step)
White Point y
0.00000 to 1.00000 (0.00002Step)
Max Disp Mastering
1 to 65535
Min Disp Mastering
0.0001 to 6.5535
Content Light LV
1 to 65535
Frame-ave Light LV
1 to 65535
ACP Packet
OFF/ON
0: OFF / 1: ON
ACP_Type
0: Generic Audio
1: IEC60958 Audio
2: DVD-Audio
3: Super Audio CD
DVD-Audio_Type
0 – 1
CopyPermission
0: Copy Freely
1: (reserved)
2: Specify CopyNumber
3: No More Copies
Copy_Number
0: 1 copies
1: 2 copies
2: 4 copies
3: 6 copies
4: 8 copies
5: 10 copies
6: 3 copies
7: Copy OneGeneration
Quality:
0 to 3
Number of
channels
Sampling frequency
Bit Width
0
2 ch or less
48kHz or lower
16 bit or less
1
2 ch or less
No restrictions
No restrictions
2
No restrictions
No restrictions
No restrictions
3
No restrictions
48kHz or lower
16 bit or less
Transaction (0/1):
0: Not Present / 1: (reserved)
Count_A :
Count_S :
Count_U :
0 to 255
CCI_Flags Q_A (0/1):
Q_S (0/1):
Q_U (0/1):
0: CD Quality / 1: Unlimited DSD Qual
CCI_Flags Move_A (0/1):
Move_S (0/1):
Move_U (0/1):
0: Not Allowed / 1: Allowed
ISRC Packet
OFF/ON ISRC1 (0/1):
ISRC2 (0/1):
0: OFF / 1: ON
ISRC_Cont (0/1):
0 to 1
ISRC_Valid (0/1):
0 to 1
ISRC_Status (0-2):
0: Starting
1: Intermediate
2: Ending
Validity Info (0-3):
0: No Validity
1: ISRC
2: UPC/EAN
3: UPC/EAN and ISRC
Catalogue Code :
13 digits each 0 to 9
