Chapter 2: Hardware Information
2-4
3. Loosen each screw one by one in the
sequence shown on the socket to open
the load plate.
4. Slightly lift open the rail frame.
5. Slide the external cap out of the rail
frame.
External cap
Load plate
Rail frame
Rail frame
External cap
PnP cap
