Chapter 2: Hardware Information
2-6
9. Twist each of the four screws with a
screwdriver just enough to attach the
heatsink to the motherboard. When the
fourscrewsareattached,tightenthem
one by one in a diagonal sequence to
completely secure the heatsink.
The heatsink screws are T20 models.
A torque value of 12 inch-lbf is
recommended.
10. Reinstall the air ducts to complete.
