(4-3) Transferring Data
A data table needs to be re-formatted for the user scale to be transferred to the PRM-100α.
Save the data in the format of a text editor for Windows.
Connect the computer and the calculation display section via the designated RS-232C cable and transfer
the data.
(4-3-1) Connecting Data Cable
Make sure that all the power is turned off, and the detection and calculation display sections of the
refractometer are connected.
Connect the computer and the calculation display section via the special RS-232C cable.
Turn the power on.
(4-3-2) Text File Format
Here is an example of formatting the NaOH data table created earlier, using a text editor.
Table 11-4
*T
5
5.0
10.0
20.0
30.0
40.0
0.0
*N
2
0.00
10.00
20.00
30.00
40.00
50.00
0.0
*C
1
1.33388
1.36050
1.38500
1.40640
1.42370
1.43590
0.0
*C
2
1.33369
1.36010
1.38440
1.40570
1.42280
1.43480
0.0
*C
3
1.33299
1.35910
1.38310
1.40410
1.42090
1.43260
0.0
*C
4
1.33194
1.35780
1.38160
1.40240
1.41900
1.43050
0.0
*C
5
1.33061
1.35640
1.38010
1.40070
1.41710
1.42840
0.0
*C
6
0.0
0.0
0.0
0.0
0.0
0.0
0.0
How to read the Table 11-4:
*T indicates the temperature data. The number "5" indicates the number of data.
The numbers to the right are the actual temperature readings.
Enter "0.0" where no data are present.
*N indicates the concentration data. The number "2" indicates the number of decimals.
Enter "0.0" where no data are present.
*C indicates the Refractive Index data. The values have been compensated for each temperature point
from 1 through 6. Enter "0.0" where no data are present.
Press the TAB key to proceed to the next cell.
Example : *T (TAB) 5 (TAB) 5.0 (TAB)
