Chapter 1. Introduction
7
5 volume + / - Press to adjust the volume of the touch panel.
6 screw holes for panel
plate
Used to secure the panel plate.
7 speakers Plays beep sounds to indicate operation actions.
8 power switch Turns the touch panel on or off.
9 power jack Connects to power.
10 reserved for
debugging purposes
These ports are reserved for debugging.
11 USB Micro-B port Reserved for debugging.
12 USB type-A port Used to update the ATEN RBS app and/or firmware.
13 LAN port with PoE Connects to the network, while receiving power via
PoE.
