Sheet #652u –
RS232
Version 1.00a
User guide
ATEQ 6th series
Page 7/8
1.1.3. Print parameters
Print parameters
: by pressing this button, the
program test parameters are printed or sent
immediately.
+0%
10(+
#761/45
RS Parameters
Print
Frame
Sending
Cond.
Expor
t
:
No
Ź
Print
parameters
Columns detail:
1) Personalization
2) Program
Number
3) Test
result
message.
4) Numerical
Test
Value.
5) Test
unit.
6) Numerical
pressure
value.
7) Pressure
Unit.
8) Alarm
Message.
8')
Bar Code (option: depends of the
device version).
9) Date.
10) Time.
