Sheet #601u – Functions management
Version 1.04a User guide ATEQ 6th series Page 19/26
1.3.6. Available functions for volume test
FUNCTIONS
Name
Pr: Sequence Next Prog. > XX+
v Inter-Cyc > 0,0 S
v All Results > No / Yes
v Pass > No / Yes
v Fail > No / Yes
v Alarm > No / Yes
v Pressure Out > No / Yes
v Reworkable > No / Yes
v Test Check > No / Yes
v
Units > SI
v USA
v Custom Leakunit >
Cal-Pa > Cal-Pa/S
> Pa > Pa/S > Pa
(Hr) > Pa (Hr)/S
v Drift Unit > 0 > 100 %
v Name
v
Automatic
Connectors
> Coupling A > 0 > 650 s
v Coupling B > 0 > 650 s
v
Fill Mode Fill Mode Standard Set Fill
v v Instruction Set Fill
v v Ballistic Set Fill
v v Fill Ramp Set Fill
v v Fill Adjust Set Fill
v v Time Adj.
v Fill regulator > 1
v 2
Dump Off > No / Yes
v
External dump > Closed
One choice for all
the programs
v Open
One choice for all
the programs
Mode > Continuous
Closed only
Time
v
Valve Codes Ext. 1 Yes
v Delay Ext 0.0 S
v Time Ext1 0.0 S
Same time for all
the programs
v Ext. 2
v Ext. 3
v Ext. 4
To Next Page
