Sheet #603u – Program sequencing function
Version 1.04a User guide ATEQ 6th series Page 1/2
PROGRAM SEQUENCING FUNCTION
This function enables several tests to be carried out by the instrument one after the other. The
instrument offers 8 program sequencing criteria.
The sequencing order can be edited; the choice of the following program is defined in the
parameters. By default the programs are sequenced according to their original number P+1.
1. PROCEDURE
Activate the function or check if i
t checked.
Press the
key, the cursor slide to the
right hand.
2#4#/ 2T
(70%6+10
Ź PR:SEQUENCE : No
More functions…
By using the arrows, select
"Yes" and validate with the
key. The
Program sequence menu is displayed.
2#4#/ 2T
(70%6+10
PR:SEQUENCE : Yes Ż
More functions…
Associated parameters to be set:
¾NEXT PROGRAM: next program to be
chained.
¾INTER-CYCLE: wait or coupling time
between the two cycles.
Chaining c
onditions:
¾ALL RESULTS: always chains to the
next program.
¾PASS: chains on a good part.
¾TEST FAIL: chain on a bad test part.
¾REFERENCE FAIL: chain on a bad
reference part.
¾ALARM: chains if an alarm is triggered.
¾PRESSURE OUT OF LIMIT: Chains if
the pressure is out of the pressure limits.
.
¾REWORKABLE: chains if reworkable is
valid.
¾CALIBRATION: volume calibration
check pass or fail.
(70%6245'37'0%
Ź NEXT PROG : 02+
INTER-CYC: 0.0 s
ALL RESULTS : No
PASS : Yes
T FAIL : No
R FAIL : No
ALARM : No
PRESSURE OUT : No
To Next Page
