Sheet #696u – USB (Automatism)
Version 1.04a User guide ATEQ 6th series Page 1/5
USB (AUTOMATISM)
The "USB" configures the USB link parameters. The USB can be connected to a printer or a
computer for data collection.
1. PROCEDURE
From the "CONFIGURATION" menu, select
the "AUTOMATISM" menu and then press the
button
/#+0%10(+)74#6+10
LANGUAGE : English
PNEUMATIC
Ź AUTOMATISM
SECURITY
MISCELLANEOUS
By using the arrows, select
the "USB" menu and validate with the
key.
#+0%10(+#761/#6+5
Ź USB : PRINTER
RS232 : PRINTER
Date & Time
INPUTS CONFIG.
Then by using the arrows
select the "PRINTER" menu, and then validate
with the
key.
Printer: to print (or send the frame) the
program parameters as well as test results.
When the option is activated, the USB
broadcasts the test results after each cycle.
Supervision: in this mode, the device switch
automatically in supervision mode when his
plugged to a PC fitted with ATEQ proprietary
software, through USB connection.
/#+0%10(+
#761/
75
SUPERVISION
Ź PRINTER
To Next Page
