Sheet #627u – Display Mode
Version 1.04a User guide ATEQ 6th series Page 1/1
DISPLAY MODE
The DISPLAY MODE function allows adjusting the number of decimal displayed by the
instrument. Available only for the flow units.
1. PARAMETRAGE
Activate the function or check if it checked.
Press the
key, the cursor slide to the
right hand.
2#4#/2T
(70%6+10
ŹDISPLAY : STANDARD
More functions…
By using the arrows, select
"Yes" and validate with the
key.
Select the preferred format.
¾STANDARD
¾XXXX
¾XXX.X
¾XX.XX
¾X.XXX
In the "Standard" mode, the instrument
displays the result with the most optimized
format.
2#4#/2T
(10%6+10
MODE AF: XX.XX Ż
+ de fonctions…
To Next Page
