ATEQ F670 - Page 13

Sheet #601u – Functions management
Version 1.04a User guide ATEQ 6th series Page 9/26
v Aux 3
v Aux 4
v
End Of Cycle > Auto Reset
v Dump + Reset
v Fill Time
v Double Reset
v
Mini-Valve > Diff A-Z > 0 > 650 s
v
Rework Limit > Test Rework
v Ref. Rework
v
Sealed
components
> Standard
v Large Leak > Coupling A > 0 > 650 s
v Fill Volume > 0 > 650 s
v Transfer > 0 > 650 s
v Dump Time > 0 > 650 s
v Press. Unit >
Bar > Mpa > Kpa
> Pa > Pts > Psi >
Mbar
v Max Fill
v Min Fill
v Set Fill
Sealed
components 3
> S
tandard
v Large Leak > Coupling A > 0 > 650 s
v Fill Volume > 0 > 650 s
Dump volume > 0 > 650 s
v Transfer > 0 > 650 s
v Dump Time > 0 > 650 s
v Press. Unit >
Bar > Mpa > Kpa
> Pa > Pts > Psi >
Mbar
v Max Fill
v Min Fill
v Set Fill
Sealed
components 2
> Standard
v Large Leak > Coupling A > 0 > 650 s
v Fill Volume > 0 > 650 s
v Transfer > 0 > 650 s
v Dump Time > 0 > 650 s
v Press. Unit >
Bar > Mpa > Kpa
> Pa > Pts > Psi >
Mbar
v Max Fill
v Min Fill
v Set Fill
N Tests > Tolerance A > 0 > 100 %
v Tolerance B > 0 > Tolerance A
