Atlas Copco GA 160 VSD

Reference Units 4 bar(e)
60 psig
7 bar(e)
100 psig
9.5 bar(e)
140 psig
13.5 bar(e)
196 psig
Cooling medium
temperature
˚F <115 <115 <115 <115
Dew-point temperature ˚C 3 3 3 3
Dew-point temperature ˚F 37 37 37 37
11.2 Reference conditions
Reference conditions
Absolute inlet pressure bar(a) 1
Absolute inlet pressure psi 14.5
Relative air humidity % 0
Air inlet temperature ˚C 20
Air inlet temperature ˚F 68
Nominal working pressure See Compressor data
Cooling medium inlet temperature ˚C 20
Cooling medium inlet temperature ˚F 68
Cooling water temperature rise °C 10
Cooling water temperature rise °F 18
11.3 Limits
Limits
Maximum air inlet/ambient temperature, GA Pack, high ambient
temperature version
˚C 55
Maximum air inlet/ambient temperature, GA Pack, high ambient
temperature version
˚F 131
Maximum air inlet/ambient temperature, GA Pack, high ambient
temperature version
˚C 55
Maximum air inlet/ambient temperature, GA Pack, high ambient
temperature version
˚F 131
Maximum air inlet/ambient temperature, GA 110 VSD up to GA
160 VSD
˚C 46
Maximum air inlet/ambient temperature, GA 110 VSD up to GA
160 VSD
˚F 115
Maximum air inlet/ambient temperature, GA 110 VSD up to GA
160 VSD, high ambient version
˚C 50
Maximum air inlet/ambient temperature, GA 110 VSD up to GA
160 VSD, high ambient version
˚F 122
Minimum air inlet/ambient temperature ˚C 0
