Atlas Copco GA 160 VSD

Compressor type
Voltage
V
Frequency
Hz Approval
Water-
Cooled Air-Cooled
Type
GA 160 VSD 380 60 IEC 3x500 A 3x500 A
DIN 43 620
size 3; high
speed fuse.
Fuse type:
AR
GA 160 VSD 440 60 IEC 3x500 A 3x500 A
DIN 43 620
size 3; high
speed fuse.
Fuse type:
AR
60 Hz CSA/UL Full Feature compressors
Compressor type
Voltage
V
Frequency
Hz Approval
Water-
Cooled Air-Cooled
Type
GA 110 VSD 460 60 CSA/UL
3x315 A 3x315 A Class T
fuse; very
fast acting
fuse
GA 110 VSD 575 60 CSA/UL
3x250 A 3x250 A Class T
fuse; very
fast acting
fuse
GA 132 VSD 460 60 CSA/UL 3x355 A 3x400 A
Class T
fuse; very
fast acting
fuse
GA 132 VSD 575 60 CSA/UL 3x315 A 3x315 A
Class T
fuse; very
fast acting
fuse
GA 160 VSD 460 60 CSA/UL 3x500 A 3x500 A
Class T
fuse; very
fast acting
fuse
GA 160 VSD 575 60 CSA/UL 3x355 A 3x355 A
Class T
fuse; very
fast acting
fuse
4.4 Electric connections
General instruction for the electrical installation of VSD compressors
• Electrical equipment from Atlas Copco Compressor is designed in accordance with the safety regulations
described in IEC60204-1 and CENELEC EN60204.
• It is the responsibility of the customer to install the compressor unit according to the safety regulations in
order to protect people from electric shocks from direct or indirect contact.
