Atlas Copco GA 45+

7 Installation
7.1 Dimension drawings
The drawings are on the CD, supplied with your machine
Dimension drawing Model
9829 3503 01 GA 37, GA 45,
GA 30
+
, GA 37
+
, GA 45
+
Text on drawings Translation or Explanation
Compressor cooling air outlet Cooling air outlet of compressor and motor
Compressor cooling air inlet Cooling air inlet of compressor and motor
Compressed air outlet Compressed air outlet connection
Electrical cable passage Electrical cable passage
Cubicle cooling air outlet Cubicle cooling air outlet
Cubicle cooling air inlet Cubicle cooling air inlet
Doors fully open Dimensions with doors fully open
Cooling water outlet Cooling water outlet connection
Cooling water inlet Cooling water inlet connection
Prepared for manual drain Prepared for manual drain
Dryer cooling air inlet Dryer cooling air inlet
Dryer cooling air outlet Dryer cooling air outlet
Centre of gravity Centre of gravity
Mass Mass of the machine
Type Machine type
Water outlet (Energy recovery - option) Water outlet (Energy recovery - option)
Water inlet (Energy recovery - option) Water inlet (Energy recovery - option)
Automatic drain, dryer Automatic drain, dryer
Automatic drain, aftercooler Automatic drain, aftercooler
Manual drain, dryer Manual drain, dryer
Manual drain, aftercooler Manual drain, aftercooler
Compressed air connection for OSCi Compressed air connection for OSCi
Electrical connection for OSCi Electrical connection for OSCi
Ambient sensor Ambient sensor
Instruction book
114 2920 7109 51
