The touchscreen and the start and stop button become inactive for 15 seconds.
4.11 Week timer menu
Function
This screen is used to set up to 4 different week timers with each up to 8 settings per day.
The week timers can be activated through this screen.
A Remaining Running Time can be set from 5 up to 240 minutes.
Procedure
To enter the Week Timer menu screen:
1. Tap the Menu button
2. Tap the Week Timer icon
Description
Reference Designation Function
(1) Add or select week If less than 4 weeks are programmed, tap the ‘+’ button to add a
week.
(2) Remove week Tap to remove a programmed week timer.
(3) Activate week timer A selection screen pops up. The user can choose the correct week
by tapping ‘–’ or ‘+’ and can confirm by tapping ‘V’ or decline by
tapping ‘X’.
(4) Remaining running
time
A selection screen pops up. The user can change the remaining time
by tapping ‘–’ or ‘+’ and can confirm by tapping ‘V’ or decline by
tapping ‘X’.
(5) Add setting A selection screen pops up. The user can change the setting by
swiping up or down and confirm by tapping ‘V’ or decline by tapping
‘X’.
4.12 Event history menu
Function
This screen is used to display the saved data in case of an alarm.
These submenus can be entered by tapping the icons.
Instruction book
2920 7109 51 75
