Function Description
Setpoints Several setpoints can be modified by tapping this icon.
Control mode The control mode can be changed by tapping this icon.
• Local control via start/stop buttons
• Remote control via digital input(s)
• LAN control via the network.
When in Remote or LAN control, the start/stop buttons on the controller will not work.
Display language The display language of the controller can be changed by tapping this icon.
Manual unload (only
on fixed speed units)
When tapped, the machine will go in Manual unload mode until the icon is tapped
again.
Week timer Week timers can be set by tapping this icon.
Remaining running
time
The Remaining running time can be set and modified by tapping this icon.
Internal SmartBox The reception quality of the internal antenna can be monitored.
Each bar represents 25% reception strength. If the four bars are filled, the reception
strength is 100%. If only one bar is filled, the reception strength is just 25%.
Auto restart Auto restart can be activated by tapping this icon.
4.6 Shutdown warning
If the element outlet temperature exceeds the shutdown warning level (see section
Programmable Settings), warning LED (2) will light up and a yellow warning icon (4) is shown in
the upper side of the display as in below image:
Tap on the select warning icon (4) to see the Status menu.
In case of element outlet temperature warning, the display will appear as below:
Instruction book
2920 7109 51 65
