Condensate drains, typical example
Reference Designation
Da Automatic drain connection
Dm Manual drain connection
Da1 Automatic drain connection of the dryer (only on Full-Feature units)
Dm1 Manual drain connection of the dryer (only on Full-Feature units)
2.6 Regulating system
Load/unload regulating system
Regulating system (loaded condition)
Instruction book
22 2920 7109 51
