Important
The readings mentioned below are valid under the reference conditions (see section
Reference conditions and limitations).
Reference Reading
Air outlet pressure Modulates between programmed unloading and loading pressures.
Compressor element
outlet temperature
For air-cooled units: approx. 60 ˚C (108 ˚F) above cooling air inlet temperature
For water-cooled units: approx. 60 ˚C (108 ˚F) above cooling water inlet
temperature.
Dewpoint temperature See section Compressor data.
Cooling water outlet
temperature
Below 50 ˚C (122 ˚F).
11.2 Electric cable size and fuses
Important
• The voltage on the compressor terminals must not deviate more than 10% of the
nominal voltage.
It is however highly recommended to keep the voltage drop over the supply cables
at nominal current below 5% of the nominal voltage (IEC 60204-1).
• If cables are grouped together with other power cables, it may be necessary to use
cables of a larger size than those calculated for the standard operating conditions.
• Use the original cable entry. See section Dimension drawings.
To preserve the protection degree of the electric cubicle and to protect its
components from dust from the environment, it is mandatory to use a proper
cable gland when connecting the supply cable to the compressor.
• Local regulations remain applicable if they are stricter than the values proposed
below.
• Currents are calculated with the full service factor but we suggest to add 10% due
to over- and under-voltage.
Fuses are maximum allowed values calculated for full service factor and 10%
over- and under-voltage.
• Caution:
• Always double-check the fuse size versus the calculated cable size. If
required, reduce fuse size or enlarge cable size.
• Cable length should not exceed the maximum length according to IEC60204
table 10
Currents and fuses
Compressor type I (1) Max. fuse (1) I (2) Max. fuse (2)
gL/gG gL/gG
V Hz A A A A
GA 30
+
200 50 132 160 145 160
GA 30
+
400 50 66 80 70 80
Instruction book
160 2920 7109 51
