7.5 bar 8.5 bar 10 bar 13 bar 100 psi 125 psi 150 psi 175 psi
Cooling water
consumption (at water
inlet temperature
between 95 and 104 ˚F
and temperature rise of
18 ˚F), water-cooled
units
cfm 2.65 2.65 2.65 2.65 2.65 2.65 2.65 2.65
Oil capacity, air-cooled
units
l 23 23 23 23 23 23 23 23
Oil capacity, air-cooled
units
US gal 6.08 6.08 6.08 6.08 6.08 6.08 6.08 6.08
Oil capacity, air-cooled
units
Imp gal 5.06 5.06 5.06 5.06 5.06 5.06 5.06 5.06
Oil capacity, water-
cooled units
l 17.9 17.9 17.9 17.9 17.9 17.9 17.9 17.9
Oil capacity, water-
cooled units
US gal 4.73 4.73 4.73 4.73 4.73 4.73 4.73 4.73
Oil capacity, water-
cooled units
Imp gal 3.94 3.94 3.94 3.94 3.94 3.94 3.94 3.94
Sound pressure level
(according to ISO 2151
(2004))
dB(A) 66 66 66 66 66 66 66 66
11.7 Technical data controller
General
Supply voltage 24 V AC /16 VA 50/60Hz (+40%/-30%)
24 V DC/0.7 A
Type of protection IP54 (front)
IP21 (back)
• Operating temperature
range
• Storage temperature
range
• -10°C…..+60°C (14 °F .....140 °F)
• -30°C…..+70°C (-22 °F ......158 °F)
Permissible humidity Relative humidity 90%
No condensation
Mounting Cabinet door
Instruction book
2920 7109 51 179
