Atmel ATtiny13A - Page 146

146
8126F–AVR–05/12
ATtiny13A
Figure 19-43. V
OL
: Reset Pin as I/O, Output Voltage vs. Sink Current (V
CC
= 3V)
Figure 19-44. V
OL
: Reset Pin as I/O, Output Voltage vs. Sink Current (V
CC
= 5V)
85 °C
25 °C
-40 °C
RESET AS I/O PIN OUTPUT VOLTAGE vs. SINK CURRENT
V
CC
= 3V
0
0,2
0,4
0,6
0,8
1
1,2
1,4
1,6
0 0,5 1 1,5 2 2,5 3
I
OL
(mA)
V
OL
(V)
85 °C
25 °C
-40 °C
RESET AS I/O PIN OUTPUT VOLTAGE vs. SINK CURRENT
V
CC
= 5V
0
0,2
0,4
0,6
0,8
1
1,2
1,4
1,6
00,511,522,533,544,55
I
OL
(mA)
V
OL
(V)
