149
8126F–AVR–05/12
ATtiny13A
Figure 19-49. V
IL
: Input Threshold Voltage vs. V
CC
(Reset Pin as I/O, Read as '0')
Figure 19-50. V
IH
-V
IL
: Input Hysteresis vs. V
CC
(Reset Pin as I/O)
RESET PIN AS I/O THRESHOLD VOLTAGE vs. VCC
V
IL
, RESET READ AS '0'
85 °C
25 °C
-40 °C
0
0.5
1
1.5
2
2.5
1.5 2 2.5 3 3.5 4 4.5 5 5.5
V
CC
(V)
Threshold (V)
RESET PIN AS IO, INPUT HYSTERESIS vs. VCC
V
IL
, I/O PIN READ AS "0"
85 °C
25 °C
-40 °C
0
0.1
0.2
0.3
0.4
0.5
0.6
0.7
0.8
0.9
1
1.5 2 2.5 3 3.5 4 4.5 5 5.5
V
CC
(V)
Input Hysteresis (V)
