Figure 19-57. V
IH
-V
IL
: Reset Input Pin Hysteresis vs. V
CC
Figure 19-58. Minimum Reset Pulse Width vs. V
CC
RESET PIN INPUT HYSTERESIS vs. V
CC
85 °C
25 °C
-40 °C
0
0.1
0.2
0.3
0.4
0.5
0.6
0.7
0.8
0.9
1
1.5 2 2.5 3 3.5 4 4.5 5 5.5
V
CC
(V)
Input Hysteresis (V)
MINIMUM RESET PULSE WIDTH vs. V
CC
85 °C
25 °C
-40 °C
0
500
1000
1500
2000
0123456
V
CC
(V)
Pulsewidth (ns)
