Figure 19-55. V
IH
: Reset Input Threshold Voltage vs. V
CC
(Reset Pin Read as '1')
Figure 19-56. V
IL
: Reset Input Threshold Voltage vs. V
CC
(Reset Pin Read as '0')
RESET INPUT THRESHOLD VOLTAGE vs. VCC
V
IH
, I/O PIN READ AS '1'
85 °C
25 °C
-40 °C
0
0.5
1
1.5
2
2.5
1.5 2 2.5 3 3.5 4 4.5 5 5.5
V
CC
(V)
Threshold (V)
RESET INPUT THRESHOLD VOLTAGE vs. VCC
V
IL
, I/O PIN READ AS '0'
85 °C
25 °C
-40 °C
0
0.5
1
1.5
2
2.5
1.5 2 2.5 3 3.5 4 4.5 5 5.5
V
CC
(V)
Threshold (V)
