• Bits 1:0 – WGM0[1:0]: Waveform Generation Mode
Combined with the WGM02 bit found in the TCCR0B Register, these bits control the counting
sequence of the counter, the source for maximum (TOP) counter value, and what type of wave-
form generation to be used, see Table 11-8 on page 73. Modes of operation supported by the
Timer/Counter unit are: Normal mode (counter), Clear Timer on Compare Match (CTC) mode,
and two types of Pulse Width Modulation (PWM) modes (see “Modes of Operation” on page 64).
Notes: 1. MAX = 0xFF
2. BOTTOM = 0x00
11.9.2 TCCR0B – Timer/Counter Control Register B
• Bit 7 – FOC0A: Force Output Compare A
The FOC0A bit is only active when the WGM bits specify a non-PWM mode.
However, for ensuring compatibility with future devices, this bit must be set to zero when
TCCR0B is written when operating in PWM mode. When writing a logical one to the FOC0A bit,
an immediate Compare Match is forced on the Waveform Generation unit. The OC0A output is
changed according to its COM0A[1:0] bits setting. Note that the FOC0A bit is implemented as a
strobe. Therefore it is the value present in the COM0A[1:0] bits that determines the effect of the
forced compare.
A FOC0A strobe will not generate any interrupt, nor will it clear the timer in CTC mode using
OCR0A as TOP.
The FOC0A bit is always read as zero.
Table 11-8. Waveform Generation Mode Bit Description
Mode WGM02 WGM01 WGM00
Timer/Counter
Mode of Operation TOP
Update of
OCRx at
TOV Flag
Set on
(1)(2)
0 0 0 0 Normal 0xFF Immediate MAX
1001
PWM
(Phase Correct)
0xFF TOP BOTTOM
2010CTC OCRAImmediateMAX
3 0 1 1 Fast PWM 0xFF TOP MAX
4100Reserved – – –
5101
PWM
(Phase Correct)
OCRA TOP BOTTOM
6110Reserved – – –
7111Fast PWM OCRATOP TOP
Bit 7 6 5 4 3 210
0x33 FOC0A FOC0B – – WGM02 CS02 CS01 CS00 TCCR0B
Read/Write W W R R R/W R/W R/W R/W
Initial Value 0 0 0 0 0 0 0 0
