102

ATtiny26(L)

1477G–AVR–03/05

Note: 1. For offset measurements only. See “Offset Compensation Schemes” on page 105.

Table 46. Input Channel and Gain Selections

MUX4..0

Single Ended

Input

Positive Differential

Input

Negative Differential

Input Gain

00000 ADC0

N/A

00001 ADC1

00010 ADC2

00011 ADC3

00100 ADC4

00101 ADC5

00110 ADC6

00111 ADC7

01000 ADC8

01001 ADC9

01010 ADC10

01011

N/A

ADC0 ADC1 20x

01100 ADC0 ADC1 1x

01101

(1)

ADC1 ADC1 20x

01110 ADC2 ADC1 20x

01111 ADC2 ADC1 1x

10000

N/A

ADC2 ADC3 1x

10001

(1)

ADC3 ADC3 20x

10010 ADC4 ADC3 20x

10011 ADC4 ADC3 1x

10100

N/A

ADC4 ADC5 20x

10101 ADC4 ADC5 1x

10110

(1)

ADC5 ADC5 20x

10111 ADC6 ADC5 20x

11000 ADC6 ADC5 1x

11001

N/A

ADC8 ADC9 20x

11010 ADC8 ADC9 1x

11011

(1)

ADC9 ADC9 20x

11100 ADC10 ADC9 20x

11101 ADC10 ADC9 1x

11110 1.18V (V

)

N/A

11111 0V (GND)
