Atmel ATtiny26 User Manual

26
ATtiny26(L)
1477G–AVR–03/05
The CKSEL0 Fuse together with the SUT1..0 Fuses select the start-up times as shown
in Table 7.
Notes: 1. These options should only be used when not operating close to the maximum fre-
quency of the device, and only if frequency stability at start-up is not important for the
application.
2. These options are intended for use with ceramic resonators and will ensure fre-
quency stability at start-up. They can also be used with crystals when not operating
close to the maximum frequency of the device, and if frequency stability at start-up is
not important for the application.
Low-frequency Crystal
Oscillator
To use a 32.768 kHz watch crystal as the clock source for the device, the Low-fre-
quency Crystal Oscillator must be selected by setting the PLLCK to “1” and CKSEL
Fuses to “1001”. The crystal should be connected as shown in Figure 22. By program-
ming the CKOPT Fuse, the user can enable internal capacitors on XTAL1 and XTAL2,
thereby removing the need for external capacitors. The internal capacitors have a nomi-
nal value of 36 pF.
When this oscillator is selected, start-up times are determined by the SUT Fuses as
shown in Table 8.
Note: 1. These options should only be used if frequency stability at start-up is not important
for the application.
Table 7. Start-up Times for the Crystal Oscillator Clock Selection
CKSEL0 SUT1..0
Start-up Time
from Power-down
Additional Delay from
Reset (V
CC
= 5.0V)
Recommended
Usage
0 00 258 CK
(1)
4.1 ms Ceramic resonator,
fast rising power
0 01 258 CK
(1)
65 ms Ceramic resonator,
slowly rising power
010 1K CK
(2)
– Ceramic resonator,
BOD enabled
011 1K CK
(2)
4.1 ms Ceramic resonator,
fast rising power
100 1K CK
(2)
65 ms Ceramic resonator,
slowly rising power
1 01 16K CK – Crystal Oscillator,
BOD enabled
1 10 16K CK 4.1 ms Crystal Oscillator, fast
rising power
1 11 16K CK 65 ms Crystal Oscillator,
slowly rising power
Table 8. Start-up Times for the Low-frequency Crystal Oscillator Clock Selection
SUT1..0
Start-up Time
from Power-down
Additional Delay from
Reset (V
CC
= 5.0V) Recommended Usage
00 1K CK
(1)
4.1 ms Fast rising power or BOD enabled
01 1K CK
(1)
65 ms Slowly rising power
10 32K CK 65 ms Stable frequency at start-up
11 Reserved
