30
ATtiny26(L)
1477G–AVR–03/05
High Frequency PLL
Clock – PLL
CLK
There is an internal PLL that provides nominally 64 MHz clock rate locked to the RC
Oscillator for the use of the Peripheral Timer/Counter1 and for the system clock source.
When selected as a system clock source, by programming (“0”) the fuse PLLCK, it is
divided by four. When this option is used, the CKSEL3..0 must be set to “0001”. This
clocking option can be used only when operating between 4.5 - 5.5V to guaratee safe
operation. The system clock frequency will be 16 MHz (64 MHz/4). When using this
clock option, start-up times are determined by the SUT Fuses as shown in Table 15.
See also “PCK Clocking System” on page 23.
Table 15. Start-up Times for the PLLCK
SUT1..0
Start-up Time from
Power-down
Additional Delay from
Reset (V
CC
= 5.0V) Recommended Usage
00 1K CK – BOD enabled
01 1K CK 4.1 ms Fast rising power
10 1K CK 65 ms Slowly rising power
11 16K CK – Slowly rising power
