127
ATtiny26(L)
1477G–AVR–03/05
Notes: 1. Typical value at 25°C
2. “Max” means the highest value where the pin is guaranteed to be read as low
3. “Min” means the lowest value where the pin is guaranteed to be read as high
4. Although each I/O port can sink more than the test conditions (20mA at Vcc = 5V, 10 mA at Vcc = 3V) under steady state
conditions (non-transient), the following must be observed:
1] The sum of all IOL, for all ports, should not exceed 400 mA.
2] The sum of all IOL, for port A0 - A7, should not exceed 300 mA.
3] The sum of all IOL, for ports B0 - B7 should not exceed 300 mA.
If IOL exceeds the test condition, VOL may exceed the related specification. Pins are not guaranteed to sink current greater
than the listed test condition.
5. Although each I/O port can source more than the test conditions (20 mA at V
CC
= 5V, 10 mA at V
CC
= 3V) under steady state
conditions (non-transient), the following must be observed:
1] The sum of all IOH, for all ports, should not exceed 400 mA.
2] The sum of all IOH, for port A0 - A7, should not exceed 300 mA.
3] The sum of all IOH, for ports B0 - B7 should not exceed 300 mA.
If IOH exceeds the test condition, VOH may exceed the related specification. Pins are not guaranteed to source current
greater than the listed test condition.
6. Minimum V
CC
for Power-down is 2.5V
I
CC
Power Supply Current
Active 1 MHz, V
CC
= 3V
(
ATtiny26L)
0.70 mA
Active 4 MHz, V
CC
= 3V
(
ATtiny26L)
2.5 6 mA
Active 8 MHz, V
CC
= 5V
(
ATtiny26)
815mA
Idle 1 MHz, V
CC
= 3V
(
ATtiny26L)
0.18 mA
Idle 4 MHz, V
CC
= 3V
(
ATtiny26L)
0.75 2 mA
Idle 8 MHz, V
CC
= 5V
(
ATtiny26)
3.5 7 mA
Power-down mode
(6)
WDT enabled, V
CC
= 3V 7.5 15 µA
WDT disabled, V
CC
= 3V 0.3 3 µA
V
ACIO
Analog Comparator
Input Offset Voltage
V
CC
= 5V
V
in
= V
CC
/2
<10 40 mV
I
ACLK
Analog Comparator
Input Leakage Current
V
CC
= 5V
V
in
= V
CC
/2
-50 50 nA
t
ACID
Analog Comparator
Propagation Delay
V
CC
= 2.7V
V
CC
= 4.0V
750
500
ns
T
A
= -40°C to 85°C, V
CC
= 2.7V to 5.5V (unless otherwise noted) (Continued)
Symbol Parameter Condition Min. Typ.
(1)
Max. Units
