Figure 108. Reset Pin as I/O – Sink Current vs. Output Voltage (V
CC
= 2.7V)
Pin Thresholds and
Hysteresis
Figure 109. I/O Pin Input Threshold Voltage vs. V
CC
(V
IH
, I/O Pin Read as “1”)
RESET PIN AS I/O - SINK CURRENT vs. OUTPUT VOLTAGE
Vcc = 2.7V
0
0.5
1
1.5
2
2.5
3
3.5
4
4.5
0 0.5 1 1.5 2 2.5
V
OL
(V)
Current (mA)
85°C
25°C
-40°C
I/O PIN INPUT THRESHOLD VOLTAGE vs. V
CC
VIH, IO PIN READ AS '1'
0
0.5
1
1.5
2
2.5
2 2.5 3 3.5 4 4.5 5 5.5
V
CC
(V)
Threshold (V)
85°C
25°C
-40°C
