Current Consumption of
Peripheral Units
Figure 136. Brown-out Detector Current vs. V
CC
Figure 137. ADC Current vs. V
CC
(AREF = AV
CC
)
BROWNOUT DETECTOR CURRENT vs. V
CC
0
0.005
0.01
0.015
0.02
0.025
0.03
0.035
2 2.5 3 3.5 4 4.5 5 5.5
V
CC
(V)
I
CC
(mA)
25°C
85°C
-40°C
ADC CURRENT vs. V
CC
AREF = AVCC
0
50
100
150
200
250
2 2.5 3 3.5 4 4.5 5 5.5
V
CC
(V)
I
CC
(uA)
85°C
25°C
-40°C
