Figure 142. Reset Supply Current vs. V
CC
(1 - 20 MHz, Excluding Current Through The Reset Pull-up)
Figure 143. Reset Pulsewidth vs. V
CC
RESET SUPPLY CURRENT vs. V
CC
1 - 20 MHz, EXCLUDING CURRENT THROUGH THE RESET PULLUP
0
2
4
6
8
10
12
14
16
18
20
02468101214161820
Frequency (MHz)
I
CC
(mA)
5.5V
4.5V
4.0V
3.3V
2.7V
3.0V
5.0V
RESET PULSE WIDTH vs. V
CC
0
200
400
600
800
1000
1200
0123
V
CC
(V)
Pulsewidth (ns)
85°C
25°C
-40°C
