Figure 39. Timer/Counter1 Synchronization Register Block Diagram
Timer/Counter1 and the prescaler allow running the CPU from any clock source while
the prescaler is operating on the fast 64 MHz PCK clock in the asynchronous mode.
Note that the system clock frequency must be lower than one half of the PCK frequency.
Only when the system clock is generated from PCK dividing that by two, the ratio of the
PCK/system clock can be exactly two. The synchronization mechanism of the asynchro-
nous Timer/Counter1 needs at least two edges of the PCK when the system clock is
high. If the frequency of the system clock is too high, it is a risk that data or control val-
ues are lost.
The following Figure 40 shows the block diagram for Timer/Counter1.
OCR1A
8-BIT DATABUS
SYNC
M
ODE
1CK delay
TCNT1
C
K
OCF1A
OCF1B
TCNT1
TOV1
OCR1B
OCR1C
TCCR1A
TCCR1B
OCR1A_SI
OCR1B_SI
OCR1C_SI
TCCR1A_SI
TCCR1B_SI
TCNT1
OCF1A
OCF1B
TOV1
TCNT1_SI
OCF1A_SI
OCF1B_SI
TOV1_SI
TCNT_SO
OCF1A_SO
OCF1B_SO
TOV1_SO
S
A
ASYNC
MODE
1PCK delay 1/2PCK -1CK delay 1/2PCK -1CK delay
P
CK
P
CKE
S
A
S
A
S
A
S
A
S
A
no delay
no delay
IO-registers
Input syncronization
registers
Timer/Counter1
Output
multiplexers
Output
syncronization
registers
