Item # Label Description
model).
Note: PoE support is a customer ordered feature.
8
FE
(Optional) Eight Fast Ethernet (10/100Base-TX) RJ-45 LAN ports for
connecting IP phones, computers, or switches. These ports support
half- and full-duplex modes, auto-negotiation, and straight or
crossover cable detection.
These ports also support PoE, complying with the IEEE 802.3af-
2003 standard. The ports automatically detect the presence of IEEE
802.3af-compliant devices. The maximum wattage available per port
is 15.4W. The maximum wattage available for all ports (GE and FE)
combined is 120W.
9 CONSOLE (Mediant
800B MSBR)
RS-232 (Mediant
800A MSBR)
RS-232 serial communication port, The port type depends on
chassis model:
 Mediant 800B MSBR: RJ-45
 Mediant 800A MSBR: 12-pin female LX40-12P Hirose connector
10
USB/WWAN
USB port that can be used for various functionalities such as 3G-
cellular WAN modem or storage capabilities. The number of ports
depends on chassis version:
 Mediant 800B MSBR: 2 USB ports
 Mediant 800A MSBR: 1 USB port

AudioCodes Mediant 800 Specifications

General

Protocols	SIP, H.323
Digital Interfaces	1/2 E1/T1 PRI
Management	Web, CLI, SNMP
Mounting	19-inch rack
Codecs	G.711, G.729, G.722, G.723.1
Power Supply	100-240V AC
Operating Temperature	0 to 40°C
Storage Temperature	-25 to 70°C
Humidity	10% to 90% non-condensing
