Analog Fast Track Guide 3. Configuring the MediaPack
Version 5.0 23 October 2006
3.3 Accessing the Embedded Web Server
¾ To access the Embedded Web Server, take these 4 steps:
1. Open a standard Web-browsing application such as Microsoft™ Internet Explorer™ (Version
6.0 and higher) or Netscape™ Navigator™ (Version 7.2 and higher).
2. In the URL field, specify the IP address of the MediaPack (e.g., http://10.1.10.10); the
Embedded Web Server’s ‘Enter Network Password’ screen appears, shown in Figure 3-2.
Figure 3-2: Embedded Web Server Login Screen
3. In the ‘User Name’ and ‘Password’ fields, enter the username (default: “Admin”) and
password (default: “Admin”). Note that the username and password are case-sensitive.
4. Click OK; the ‘Quick Setup’ screen is accessed, shown in Figure 3-3 (MGCP), Figure 3-4
(H.323), and Figure 3-5 (SIP).
3.4 Basic Control Protocol Parameters
To configure the MediaPack basic control protocol parameters use the Embedded Web Server’s
‘Quick Setup’ screen.
For MGCP, refer to Section 3.4.1 on page 23.
For H.323, refer to Section 3.4.2 on page 25.
For SIP, refer to Section 3.4.3 on page 27.
When you have completed the above relevant section, you are then ready to start using the
MediaPack. For information on how to fully configure the VoIP gateway, refer to the MediaPack
User’s Manuals.
Tip: Once the gateway is configured correctly, back up your settings by saving the
VoIP gateway configuration (ini file) in a directory on your PC. This saved file
can be used to restore configuration settings at a future time. For information on
backing up and restoring the gateway’s configuration, refer to Section 5 on page
31.
Note: The configuration sections from here up to and including Section 3.4.3 on page
27 apply individually to MGCP, H.323, or SIP.
MGCP configuration continues with Section 3.4.1 on page 23.
H.323 configuration continues with Section 3.4.2 on page 25.
SIP configuration continues with Section 3.4.3 on page 27.
