AudioCodes MP-124 Fast Track Guide

Analog Fast Track Guide 7. Upgrading the MediaPack
Version 5.0 35 October 2006
3. Click the Start Software Upgrade button; the ‘Load a cmp file’ screen appears (Figure 7-2).
Note: When in the wizard process, the rest of the Web application is unavailable and
the background Web screen is disabled. After the process is completed,
access to the full Web application is restored.
Figure 7-2: Load a cmp File Screen
4. Click the Browse button, navigate to the cmp file, and then click Send File; the cmp file is
loaded to the device and you’re notified as to a successful loading (refer to Figure 7-3).
Figure 7-3: cmp File Successfully Loaded into the Device Notification
5. Note that the four action buttons (Cancel, Reset, Back, and Next) are now activated
(following cmp file loading).
http://ArtTel.ru

AudioCodes MP-124 Specifications

General

Model	MP-124
Category	Gateway
Analog Ports	24 FXS
Ethernet Ports	2
Protocol Support	SIP, H.323
Fax Support	T.38, G.711 pass-through
Power Supply	100-240VAC, 50-60Hz
Operating Temperature	0°C to 40°C
Voice Codecs	G.711, G.729, G.723.1, G.726
Management	SNMP
Storage Temperature	-20°C to 70°C
Humidity	10% to 90%, non-condensing
Network Interface	10/100Base-T Ethernet
