MediaPack
Analog Fast Track Guide 28 Document #: LTRT-59805
5. Configure ‘Enable Registration’ to ‘Yes’ or ‘No’:
• ‘No’ = the MediaPack doesn't register to a Proxy server/Registrar (default).
• ‘Yes’ = the MediaPack registers to a Proxy server/Registrar at power up and every
‘Registration Time’ seconds; The MediaPack sends a register request for each channel
or for the entire gateway (according to the ‘Authentication Mode’ parameter). For
detailed information on the parameters ‘Registration Time’ and ‘Authentication Mode’,
refer to the MediaPack SIP User’s Manual.
6. Select the coder (i.e., vocoder) that best suits your VoIP system requirements. The default
coder is: G.723.1 30 msec. To configure the entire list of coders you want the MediaPack to
use, refer to the MediaPack User’s Manual.
7. Map outgoing calls to IP addresses (when Proxy isn’t used) by completing these steps:
a. Click the arrow button next to the ‘Tel to IP Routing Table’ label; the ‘Tel to IP Routing’
screen opens.
Any telephone number whose destination number matches the prefix defined in the
‘Destination Phone Prefix’ field and whose source number matches the prefix defined in
the adjacent ‘Source Phone Prefix‘ field, is sent to the IP address entered in the ‘IP
Address’ field.
b. Click the Submit button; the ‘Tel to IP Routing’ table is automatically updated.
c. Click Quick Setup; you’re returned to the ‘Quick Setup’ screen.
For more information on the ‘Tel to IP Routing’ table refer to the MediaPack SIP User’s
Manual.
8. Allocate MediaPack endpoints (analog lines) and their corresponding phone numbers to
incoming IP calls by completing these steps:
a. Click the arrow button next to the ‘Endpoint Phone Number’ label; the ‘Endpoint Phone
Numbers’ screen opens.
b. Enter the number of a channel, starting with 1, (or a group of channels), under the
‘Channel(s)’ column (for example 1-4 for the first 4 endpoints).
c. Assign each channel a phone number (for a group of channels, define the first number
in an ordered sequence) For an example of connecting two MP-118 devices, refer to
Section 3.4.4 on page 29.
d. Click the Submit button; the ‘Endpoint Phone Number’ table is automatically updated.
e. Click Quick Setup; you’re returned to the ‘Quick Setup’ screen.
9. On the main menu bar, click the Maintenance button; the 'Maintenance Actions' screen is
displayed. From the 'Burn to FLASH' drop-down list, select 'Yes', and then click the Reset
button; the MediaPack applies the changes and restarts. This takes approximately two
minutes to complete. When the MediaPack completes restarting, the Power and Ready
LEDs on the front panel are lit green.
Note: SIP users should continue with Section 3.4.4, "Example of Connecting Two MP-
118 Devices" on page 29.
