AUTOFLAME Mk8 MM Installation And Commissioning Guide

6 Draught Control
Page 108 Mk8 MM Expansion Features Installation and Set-Up Guide 04.09.2016
6.3.2 Ways of Using Draught Servomotor
The draught servomotor can be used for draught control trim with an air pressure sensor, or as a
draught servomotor which drives to commissioned positions along the firing curve.
Figure 6.3.2.i Draught Servomotor
Figure 6.3.2.i shows the draught servomotor enabled without draught control trim.
