AUTOFLAME Mk8 MM Installation And Commissioning Guide

239mm
(9.41”)
137.5mm
(5.41”)
130mm
(5.11”)
80mm
(3.15”)
26mm
(1.02”)
25mm
(0.98”)
74.5mm
(2.93”)
5 Bottom Blowdown
04.09.2016 Mk8 MM Expansion Features Installation and Set-Up Guide Page 89
5.3.2 Bottom Blowdown Module
If the bottom blowdown module is used with the MM, please follow the commissioning and blowdown
timing configuration steps in section 5.4. If the bottom blowdown module is used as a standalone unit,
please refer to the PC Software Guide for instructions on using the Bottom Blowdown Board
Configurator software.
Dimensions
