2 Expansion Options
04.09.2016 Mk8 MM Expansion Features Installation and Set-Up Guide Page 7
2 EXPANSION OPTIONS
The Options, Parameters and Expansion Options must only be changed by factory
trained and certified technicians who have a thorough appreciation of the Autoflame
combustion systems and the combustion process in general. Any person changing these
settings without the correct factory training and understanding of the boiler plant may
place themselves and others in a potentially dangerous situation.
CH1, CH2, CH3, CH4, CH5, CH6 and CH7 refer to the rows of buttons respectively
start with CH1 at the top.
The options, parameters and expansion options are all viewable while the MM is in run mode. In
commissioning mode, all of the options, parameters and expansion options can be adjusted according
to the application. Non safety-critical options, parameters and expansion options can be adjusted
through Online Changes.
Press in the Commission Mode screen to access the Expansion Options. Any number of
expansion options can be changed at on time. By pressing WLC, TBD, BBD, DC, Modbus FO and Flow
at the bottom of the screen, the expansion options can be grouped together by feature.
When the changes have been made to suit the application’s needs, press Exit to go back to the
Commission Mode screen.
To set all the options, parameters and expansion options to the default values and erase the
commissioning data, set option/ parameter 160 to 5. The MM will then automatically restart.
Note: The Expansion Feature must be unlocked by sending the code for that MM via
Download Manager. Please see PC Software Guide on unlocking Expansion Features.
Unlockable Software Feature Part Number
Autoflame Water Level MK8001
Analogue Water Level (requires Autoflame Water Level) MK8002
Top Blowdown MK8003
Bottom Blowdown MK8004
Draught Control MK8005
Direct Modbus MK8006
First Out Annunciation MK8007
Fully Metered Combustion System MK8008
Heat Flow (Steam Flow + Hot Water Flow) MK8009
