AUTOFLAME Mk8 MM Installation And Commissioning Guide

1 Technical Specifications
Page 2 Mk8 MM Expansion Features Installation and Set-Up Guide 04.09.2016
1.2 Expansion Board Inputs and Outputs
Outputs: 120/230 V All outputs with the exception of PF are switched neutrals
BFW 250mA Must be connected through contactor
BB 250mA Must be connected through contactor
HWV 100mA (alarm indicator)
2LA 100mA (alarm indicator)
2LV 100mA (alarm indicator)
H1A 100mA (alarm indicator)
1LV 100mA (alarm indicator)
79 100mA (alarm indicator on MM board)
TB 250mA Solenoid only, must be connected through contactor
PF Maximum 2A (load currents for above terminals)
Note: Max number of alarm indicators on at any time is 3 (1LV, 2LA, 2LV)
Main Voltage Signal Inputs:
At 120V current loading is approximately maximum 0.7mA per input.
At 230V current loading is approximately maximum 1.5mA per input.
1.2.1 Fuse Ratings
Fuse Rating Spare Part Number
1 6.3A (T) FU10026
 Fuse 1 protects the mains input to the MM, including the mains output terminals 50 – 64.
2 2A (T) FU10034
 Fuse 2 protects the power supply (terminal 69) for the servomotors, alarm and 2 port valve. If this
fuse blows, the error ‘Triac Power Supply Error (Check F2)’ will occur.
3 500mA FU10040
 Fuse 3 protects the 13.5V power supply to the oil pressure sensor and IR scanner on terminal 49. If
this fuse blows, the error ‘Fused 13.5V Supply Error (Check F3)’ will occur.
4 500mA 500mA
 Fuse 5 protects the power supply (terminal PF) for the expansion servos and alarm outputs. If fuse
5 blows, the error ‘Expansion PF Output (Check F5)’ will occur.
5 2A (T) FU10034
 Fuse 5 protects the power supply (terminal PF) for the expansion servos and alarm outputs. If fuse
5 blows, the error ‘Expansion PF Output (Check F5)’ will occur.
6 2A FU10027
 Fuse 6 protects the DC circuits. If this fuse blows, the display will be off and both LEDs adjacent to
fuse 7 and 8 will be off.
7 4A FU10050
 Fuse 7 protects the internal 5V supply. If this fuse blows the display will be off and the LED
adjacent to the fuse will be off.
8 2.5A FU10042
 Fuse 8 protects the internal 12V supply. If this fuse blows the display will be off and the LED
adjacent to the fuse will be off.
