3 Water Level Control
04.09.2016 Mk8 MM Expansion Features Installation and Set-Up Guide Page 31
3.3.2 Configuration
The following tables show the expansion options which need to be set on the Mk8 MM for the different
ways of water level detection.
Expansion Option Description Setting
1. One capacitance probe, external level sensor
1 Water level control function 1
3 Capacitance probes 1
4 External level sensor 1
27 Probe mismatch threshold As required
28 Capacitance probe still water threshold As required
29 Capacitance probe filter time As required
30 External level sensor scaling As required
31 External level sensor filter time As required
2. One capacitance probe, external level sensor, auxiliary alarm inputs
1 Water level control function 1
3 Capacitance probes 1
4 External level sensor 1
5 Auxiliary alarm inputs 1
27 Probe mismatch threshold As required
28 Capacitance probe still water threshold As required
29 Capacitance probe filter time As required
30 External level sensor scaling As required
31 External level sensor filter time As required
3. One capacitance probe, external level sensor, 2
nd
low probe
1 Water level control function 1
3 Capacitance probes 1
4 External level sensor 1
6 Second low probe 1
27 Probe mismatch threshold As required
28 Capacitance probe still water threshold As required
29 Capacitance probe filter time As required
30 External level sensor scaling As required
31 External level sensor filter time As required
4. One capacitance probe, external level sensor, 2
nd
low probe, auxiliary alarm inputs
1 Water level control function 1
3 Capacitance probes 1
4 External level sensor 1
5 Auxiliary alarm inputs 1
6 Second low probe 1
27 Probe mismatch threshold As required
28 Capacitance probe still water threshold As required
29 Capacitance probe filter time As required
30 External level sensor scaling As required
31 External level sensor filter time As required
