AUTOFLAME Mk8 MM Installation And Commissioning Guide

3 Water Level Control
Page 32 Mk8 MM Expansion Features Installation and Set-Up Guide 04.09.2016
5. One capacitance probe, 2
nd
low probe
1 Water level control function 1
3 Capacitance probes 1
6 Second low probe 1
27 Probe mismatch threshold As required
28 Capacitance probe still water threshold As required
29 Capacitance probe filter time As required
6. One capacitance probe, 2
nd
low probe, auxiliary alarm inputs
1 Water level control function 1
3 Capacitance probes 1
5 Auxiliary alarm inputs 1
6 Second low probe 1
27 Probe mismatch threshold As required
28 Capacitance probe still water threshold As required
29 Capacitance probe filter time As required
7. One capacitance probe, auxiliary alarm inputs
1 Water level control function 1
3 Capacitance probes 1
5 Auxiliary alarm inputs 1
27 Probe mismatch threshold As required
28 Capacitance probe still water threshold As required
29 Capacitance probe filter time As required
8. Two capacitance probes
1 Water level control function 1
3 Capacitance probes 2
27 Probe mismatch threshold As required
28 Capacitance probe still water threshold As required
29 Capacitance probe filter time As required
9. Two capacitance probes, auxiliary alarm inputs
1 Water level control function 1
3 Capacitance probes 2
5 Auxiliary alarm inputs 1
27 Probe mismatch threshold As required
28 Capacitance probe still water threshold As required
29 Capacitance probe filter time As required
10. Two capacitance probes, 2
nd
low probe
1 Water level control function 1
3 Capacitance probes 2
6 Second low probe 1
27 Probe mismatch threshold As required
28 Capacitance probe still water threshold As required
29 Capacitance probe filter time As required
