AUTOFLAME Mk8 MM Installation And Commissioning Guide

3 Water Level Control
04.09.2016 Mk8 MM Expansion Features Installation and Set-Up Guide Page 33
11. Two capacitance probes, 2
nd
low probe, auxiliary alarm inputs
1 Water level control function 1
3 Capacitance probes 2
5 Auxiliary alarm inputs 1
6 Second low probe 1
27 Probe mismatch threshold As required
28 Capacitance probe still water threshold As required
29 Capacitance probe filter time As required
12. Two capacitance probes, external level sensor
1 Water level control function 1
3 Capacitance probes 2
4 External level sensor 1
27 Probe mismatch threshold As required
28 Capacitance probe still water threshold As required
29 Capacitance probe filter time As required
30 External level sensor scaling As required
31 External level sensor filter time As required
13. Two capacitance probes, external level sensor, auxiliary alarm inputs
1 Water level control function 1
3 Capacitance probes 2
4 External level sensor 1
5 Auxiliary alarm inputs 1
27 Probe mismatch threshold As required
28 Capacitance probe still water threshold As required
29 Capacitance probe filter time As required
30 External level sensor scaling As required
31 External level sensor filter time As required
14. Two capacitance probes, external level sensor, 2
nd
low probe
1 Water level control function 1
3 Capacitance probes 2
4 External level sensor 1
6 Second low probe 1
27 Probe mismatch threshold As required
28 Capacitance probe still water threshold As required
29 Capacitance probe filter time As required
30 External level sensor scaling As required
31 External level sensor filter time As required
15. Two capacitance probes, external level sensor, 2
nd
low probe, auxiliary alarm inputs
1 Water level control function 1
3 Capacitance probes 2
4 External level sensor 1
5 Auxiliary alarm inputs 1
6 Second low probe 1
27 Probe mismatch threshold As required
28 Capacitance probe still water threshold As required
29 Capacitance probe filter time As required
30 External level sensor scaling As required
31 External level sensor filter time As required
