3 Water Level Control
Page 34 Mk8 MM Expansion Features Installation and Set-Up Guide 04.09.2016
16. External level sensor, auxiliary alarm inputs
1 Water level control function 1
4 External level sensor 1
5 Auxiliary alarm inputs 1
30 External level sensor scaling As required
31 External level sensor filter time As required
17. Auxiliary alarm inputs, 2
nd
low probe
1 Water level control function 1
5 Auxiliary alarm inputs 1
6 Second low probe 1
18. External level sensor, 2
nd
low probe
1 Water level control function 1
4 External level sensor 1
30 External level sensor scaling As required
31 External level sensor filter time As required
Please see section 3.4 for more information on capacitance probes.
Please see section 3.5 for more information on 2
nd
low safety probe.
Please see section 3.6 for more information on external level sensor.
Please see section 3.7 for more information on auxiliary alarm inputs.
