AUTOFLAME Mk8 MM Installation And Commissioning Guide

9 Heat Flow
04.09.2016 Mk8 MM Expansion Features Installation and Set-Up Guide Page 129
9 HEAT FLOW
9.1 Overview
9.1.1 Benefits of Steam/Hot Water Flow Metering
The purpose of steam/hot water flow metering is to measure the amount of steam or hot water which is
being produced, and to check the amount of heat this is delivering. The majority of plants will require
steam flow metering to check how much steam is being generated and used, and at what cost, so the
overall plant efficiency can be determined.
Steam flow meters are very expensive to purchase and install, however with the Autoflame system, the
simplest form of steam or hot water flow metering can be set with just using the default values.
Autoflame has been granted a worldwide patent on the steam/hot water flow metering function in the
software.
9.1.2 Configuration
To activate steam or heat flow metering on the Mk8 MM, the Heat Flow software feature must be
unlocked. The activation code for the serial number of the MM will need to be purchased using part
number MK8009, and uploaded to the unit via Download Manager software.
Please see Autoflame PC Software Guide for more information on unlocking expansion features on the
Mk8 MM using Download Manager software.
The table below shows the terminals used for the steam flow metering.
Terminal Description
- Common for terminals T1, T2 and T3
T1 Signal input from T1 temperature sensor
T2 Signal input from T2 temperature sensor
T3 Signal input from T3 temperature sensor
F- Common for terminals MF and CF
MF Current input, 4-20mA for cold water make up flow meter
CF Current input, 4-20mA for condensate return flow meter
The table below shows the expansion option used for steam flow metering.
Expansion Option Description
120 Heat flow function
121 Boiler standing losses
122 Blow down losses
123 Blow down loss calculation method
124 Make up flowmeter range
125 Condensate flow meter range
126 Default feed water temperature
127 Steam flow start pressure offset
128 Steam flow stop pressure offset
129 Heat flow data source
Note: Fuel flow metering is required for steam/hot water flow metering.
