7 Remote Control
04.09.2016 Mk8 MM Expansion Features Installation and Set-Up Guide Page 113
7.2 Configuration
The following expansion options will need to be set on the Mk8 MM for direct Modbus.
Expansion Option Description Setting
100 Sequencing/DTI or Modbus function 1
101 Modbus baud rate As required
102 Modbus parity setting As required
103 Modbus stop bits setting As required
104 Modbus device ID As required
105 Binary format As required
The following terminals are used for direct Modbus.
Terminal Description
27 RS485 -
28 RS485 +
S Screen
